The function of the IWP wiper is cleaning the rod while return into position, blocking external impurities. It is made up of an external metal cage core part glued to a PU element. It has widely used on earth moving machinery and agricultural machinery. For the limited size can be used to protect joints, bearings and bushings rolling (pin dust seal). The groove is open and makes easier the design of the seat.

PRODUCT ADVANTAGES

• Superior wiping performance
• Used in heavy conditions by the good tear and rupture properties of PU material
• Superior protection against particles in the external environment

APPLICATION

• Construction machinery
• Forklifts
• Injection moulding machines
• Standard industrial cylinders

MaterialCode
PU93° Shore A (CA)
SHEETNORMS DIN 1624

OPERATING CONTITIONS

Temperature-35 °C
+100 °C (Peaks: +110 °C)
Pressure
Speed≤0.8 m/sec
